Product Operation Principle
Detects broken glass using an electret microphone, which registers the sound of impact against the glass and of the glass falling.
Two-factor detection of broken glass prevents false alarms caused by thunder, dogs barking and noise from passing trucks.
Installation and Set up of Product
Ready to operate straight out the box: the battery is already installed, therefore there is no need to disassemble the detector. With one click, it can be connected to the hub in the mobile application. It can be mounted on the SmartBracket in just a few minutes.
|Sensitive element||Electret microphone|
|Glass break detection distance||Up to 9 m|
|Microphone coverage angle||180°|
|Frequency band||868.0 – 868.6 MHz or 868.7 – 869.2 MHz depending on the region of sale|
|Compatibility||Operates with all Ajax hubs, range extenders, ocBridge Plus, uartBridge|
|Maximum RF output power||Up to 20 mW|
|Radio signal modulation||GFSK|
|Radio signal range||Up to 1,000 m (any obstacles absent)|
|Socket for connecting wire detectors||Yes, NC|
|Power supply||1 battery CR123A, 3 V|
|Battery life||Up to 7 years|
|Operating temperature range||From -10°С to +40°С|
|Operating humidity||Up to 75%|
|Overall dimensions||Ø 20 × 90 mm|
|Certification||Security Grade 2, Environmental Class II in conformity with the requirements of EN 50131-1, EN 50131-2-7-1, EN 50131-5-3|
AJAX GlassProtect User Manual : Click Here
Replacement and repair within 24 months of the date of sale. Batteries are not covered under warranty.
What’s in the Box?
- AJAX GlassProtect x 1
- SmartBracket mounting panel x 1
- Battery CR123A (pre-installed) x 1
- Outside-mounted terminal clamp x 1
- Installation kit x 1
- Quick Start Guide x 1
