Product Operation Principle
The device has IP54 dust and moisture protection. 12 V DC external power supply can be connected, if necessary. The built-in accelerometer will raise the alarm if an attempt is made to remove the siren.
Installation and Set Up of Product
Ready to operate straight out the box: the battery is already installed, therefore there is no need to disassemble the siren. With one click, it can be connected to the hub in the mobile application. It can be mounted on the SmartBracket in just a few minutes.
|Type of notification||Sound and light (LEDs)|
|Sound notification volume||85 dB to 113 dB at a distance of 1 m (adjustable)|
|Operating frequency of the piezo annunciator||3.5 ± 0.5 kHz|
|Protection against dismounting||Accelerometer|
|Frequency band||868.0 – 868.6 MHz or 868.7 – 869.2 MHz depending on the region of sale|
|Compatibility||Operates with all Ajax hubs, and range extenders|
|Maximum RF output power||Up to 25 mW|
|Modulation of the signal||GFSK|
|Radio signal range||Up to 1,500 m (any obstacles absent)|
|Power supply||4 × CR123A, 3 V|
|Battery life||Up to 5 years|
|External supply||12 V, 1.5 A DC|
|Body protection level||IP54|
|Operating temperature range||From -25°С to +50°С|
|Operating humidity||Up to 95%|
|Overall dimensions||200 × 200 × 51 mm|
|Certification||Security Grade 2, Environmental Class III in conformity with the requirements of EN 50131-1, EN 50131-4, EN 50131-5-3|
AJAX StreetSiren User Manual : Click Here
Replacement and repair within 24 months of the date of sale. Batteries are not covered under warranty.
What’s in the Box?
- AJAX StreetSiren x 1
- SmartBracket mounting panel x 1
- Battery CR123A (pre-installed) x 4
- Installation kit x 1
- Quick Start Guide x 1
