Description
Product Highlights
- Wireless class: AC1300 + HomePlug AV600
- Wi-Fi + PLC Hybrid Mesh: Hybrid network boosts bandwidth effectively. With powerline, there is no more walls or distance limits. Enjoy home Wi-Fi everywhere!
- Powerful Processing: Qualcomm Quad-core CPU
- Simple and Smart: With Deco App, it is a breeze to setup and manage the network. Hardware is compatible to work with Amazon Alexa and IFTTT.
- Maximized Range: Wi-Fi coverage up to 2000 sq. ft. for each single unit
- More devices to connect: Supports over 100 devices connection
- TP-Link HomeCareTM : Combined with parental controls, QoS and router built-in antivirus softwar
Product Catalogue
Product Specification
POWER | |
---|---|
AC adapter input | 100-240V ~ 50/60Hz 0.4A |
AC adapter output | 12V ⎓ 1.2A |
HARDWARE FEATURES | |
---|---|
Ports | 2 * LAN/WAN Gigabit Ethernet Ports 1 * USB Type-C Port |
Button | 1 Reset button on the underside |
External Power Supply | 12 V/1.2 A |
Flash | 32 MB |
SDRAM | 256 MB |
LED | 1 LED |
Dimensions | Φ4.7 in. x 1.3 in. (Φ120 mm x 38 mm) |
Antenna Type | 4 internal antennas per Deco unit |
WIRELESS FEATURES | |
---|---|
Wireless Standards | IEEE 802.11 ac/n/a 5 GHz, IEEE 802.11 b/g/n 2.4 GHz |
Frequency | 2.4 GHz and 5 GHz |
Wireless Onboarding | Bluetooth 4.2 |
Signal Rate | 867 Mbps at 5 GHz 400 Mbps at 2.4 GHz |
Transmit Power | FCC: <30 dBm CE: <20 dBm (2.4 GHz) <23 dBm (5 GHz) |
Wireless Security | WPA-PSK/WPA2-PSK |
Advanced Functions | ● Router/ Access Point Mode ● Optional Ethernet Backhaul ● TP-Link Mesh Technology: MU-MIMO Auto Path Selection AP Steering Band Steering Beamforming |
SOFTWARE FEATURES | |
---|---|
Quality of Service | WMM |
WAN Type | Dynamic IP/Static IP/PPPoE |
Management | Local Management, Remote Management |
DHCP | Server, Client |
Firewall Security | SPI Firewall |
Protocols | Supports IPv4 and IPv6 |
Advanced Features | Parental Controls 3-Year Built-In Antivirus QoS (Quality of Service) Reporting Assisted Setup |
Guest Network | 2.4 GHz guest network * 1 5 GHz guest network * 1 |
POWERLINE | |
---|---|
Powerline Rate | 600Mbps |
Standard | HomePlug AV |
Range | 300 meters / 1000 feet over electrical circuit |
OTHERS | |
---|---|
Package Contents | ●Deco P7 (3-pack): 3 Deco units 1 RJ45 Ethernet Cable 3 Power Adapters with Powerline●Deco P7 (2-pack): 2 Deco units 1 RJ45 Ethernet Cable 2 Power Adapters with Powerline |
Smartphone/Tablet Requirements | iOS 8.0 or later Android 4.3 or later Bluetooth 4.0 or later |
Environment | Operating Temperature: 0℃~40℃ (32℉~104℉) Storage Temperature: -40℃~70℃ (-40℉~158℉) Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing |
Product Warranty
1 year
